🟠 Thin layers scraper (tiny+ergonomic)
#tool
#rounded
#accessory
#round
#scraper
#spatula
#3dprint
#ergonomic
#3dprintaccessories
#scrapertool
#360scraper
Description
UPDATE 3.1.2023: - added V2 version with different inner shaping → same external size & characteristics, quicker print
Info: - 🟠 round edge → longer edge → scraper lasts longer then other spatula types scrapers - if it is less sharp on one side, you can just use the other side
- 🤗 ergonomic pleasant holding
- 💪 easier pressing against the plate (comparing to spatula type scapers) - with spatula it is hard to press on one segment of the edge, with round shape it is easy
- 🤑 much smaller filament consumption (comparing to spatula type scrapers)
- 🍩 with hole, so it can be hanged
✅ With this you will remove every thin layer super-easily!
Quick review in a video from JanTec:
TIP: If the handle part is too low for you → you can try TALL edition of this model: https://www.printables.com/model/341401-round-scraper-tall-edition
Print info: - material: - PLA or anything hard (but people are using PETG as well)
- layers: - a lot of people just use 0.2mm and are happy with it
- but you can use variable layer height for finer results (down to 0.07mm where needed -bottom and top part) → see 3mf/gcode example
- TIP: use skirt of 1 layer height for immediate test :)
❗ How to remove it from the plate after printing: - metal removable plate: - just take the plate away from printer and bend it - model will be removed by itself
- glass plate (non removable): - well you may have little problem, people are solving it by putting some tool in the hole in the print (like a wrench) and by some force they pull it off
Inspiration: - i was using for a long time this rounded scraper from BaGoon - I was happy with it, because given shape is by far the best for removing any thin layer of printed object
- BUT it was uncomfortable to hold it, sometimes even painful (too small sharp holds)
Happy scraping!
